| 1 | 450-441 | BRACKET | |
| 2 | 105-274 | BOLT | |
| 3 | 455-220 | WASHER | |
| 4 | 451-397 | CLIP | |
| 5 | 454-072 | PILOT VALVE,(SEE FIG.Y1670-01A0) | |
| 6 | 453-158 | LEVER | |
| 7 | 107-985 | BOLT | |
| 8 | 455-220 | WASHER | |
| |9 | 450-277 | BOOT ASS'Y | |
| 9 | 450-275 | BOOT | |
| 10 | 450-356 | BRACKET | |
| 11 | 453-086 | SWITCH¤ KNOB | |
| 12 | 454-960 | NUT | |
| 13 | 451-537 | COLLAR | |
| 14 | 450-109 | BAND | |
| 15 | 453-424 | NIPPLE | |
| 16 | 453-695 | O-RING | |
| 17 | 456-652 | BOLT | |
| 18 | 450-670 | PLUG | |
| 19 | 453-705 | O-RING | |
| 20 | 450-446 | BRACKET | |
| 21 | 107-968 | BOLT | |
| 22 | 455-225 | WASHER | |
| 23 | 457-089 | HOSE | |
| 24 | 450-129 | BAND¤ YELLOW | |
| 25 | 450-122 | BAND¤ BLACK | |
| 26 | 450-123 | BAND¤ BLUE | |
| 27 | 450-127 | BAND¤ RED | |
| 28 | 451-763 | COVER | |
| 29 | 457-092 | HOSE |
