Запчасти впрыск двигатели 210m qsk19 engine Komatsu



|$0 1310 483 H91 INJECTOR
1 1238 401 H1 BALL, CHECK
2 1238 696 H1 SEAL, O-RING
3 1238 793 H1 SEAL, INJECTOR
4 1307 955 H1 SEAL, O-RING
5 1307 956 H1 SCREEN, FILTER
6 NSS SPRING, INJECTOR
7 1307 958 H1 HOUSING, TOP STOP SPRING
8 NSS NUT, LOCK
9 NSS CAP, INJECTOR TOP STOP
10 NSS GUIDE, SPRING
11 NSS RETAINER, INJECTOR LINK
12 NSS SPRING, INJECTOR
13 1307 964 H1 SCREEN, FILTER
14 1307 965 H1 SEAL, O-RING
15 1307 966 H1 SEAL, O-RING
16 1307 967 H1 SEAL, O-RING
17 1307 968 H1 RING, RETAINING
18 1307 969 H1 RING, RETAINING
19 NSS HOUSING, INJECTOR SPRING
20 1307 971 H1 RETAINER, INJECTOR NOZZLE
21 NSS GUIDE, SPRING
22 NSS GUIDE, SPRING
23 1238 429 H1 GASKET, INJECTOR
24 NSS PLUG, INJECTOR ORIFICE
25 NSS PLUNGER, INJECTOR
26 NSS NOZZLE, INJECTOR
27 NSS PLUNGER, INJECTOR
28 NSS COUPLING, INJECTOR PLUNGE
29 NSS BARREL, INJECTOR
30 NSS PLUNGER, INJECTOR TIMING
31 NSS LINK, INJECTOR PLUNGER
32 NSS RING, FUEL DEFLECTOR
33 1307 982 H1 BOLT
34 1307 983 H1 CLAMP, INJECTOR
|$38
|$35 R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED
|$36 ASSEMBLIES CATALOG.
21
9
33
6
10
8
22
34
12
17
7
25
30
16
19
31
4
29
1
11
23
23
24
24
26
28
5
14
2
18
27
32
20
13
15
3
X
