Запчасти топливн. трубы двигатели 210m qsk19 engine Komatsu



1 1237 987 H1 BOLT (5/16 - 18x2.25 INCH)
2 1237 999 H1 BOLT (5/16 - 18x0.875 INCH)
3 1238 015 H1 BOLT (3/8 - 16x0.75 INCH)
4 25 522 R1 NUT, HEAVY HEXAGON (3/8 - 16)
5 1238 099 H1 WASHER, PLAIN
6 120 382 WASHER, LOCK (3/8)
7 1238 235 H1 WASHER, PLAIN
8 1239 571 H91 VALVE, CHECK
9 1307 817 H1 CLIP
10 1307 818 H1 ELBOW, MALE UNION
11 1307 822 H1 BRACE, TUBE
|$11 1307 819 H91 TEE, MALE BRANCH
12 1307 820 H1 SEAL, O RING
13 1307 821 H1 TEE, MALE BRANCH
|$14 1307 823 H91 ELBOW, MALE UNION
12 1307 820 H1 SEAL, O RING
14 1246 119 H1 SEAL, O RING
15 1307 824 H1 ELBOW, MALE UNION
16 1307 825 H1 TUBE, FUEL DRAIN
17 1307 826 H1 TUBE, FUEL DRAIN
18 1307 827 H1 CLAMP, TUE
19 1307 828 H1 BRACKET, CHECK VALVE
17
18
18
18
7
12
1
13
12
12
18
15
18
14
11
19
7
7
2
1
18
5
10
16
4
6
3
9
8
