| |$0 | 1307 729 H91 | CRANKSHAFT | |
| 1 | NSS | CRANKSHAFT | |
| 2 | 1307 730 H1 | GEAR, CRANKSHAFT | |
| 3 | 1238 769 H1 | KEY, WOODRUFF | |
| |$4 | 1237 924 H91 | SHELL, MAIN BEARING (STD) | |
| 4 | 1238 673 H1 | BEARING, MAIN (# 2, 3, 4, 5 & 6 - UPPER) | |
| 5 | 1238 677 H1 | BEARING, MAIN (# 2, 3, 4, 5 & 6 - LOWER) | |
| 6 | 1238 682 H1 | BEARING, MAIN (# 1 & 7 - LOWER) | |
| 7 | 1238 688 H1 | BEARING, MAIN (# 1 & 7 - UPPER) | |
| 9 | 1238 666 H1 | BEARING, THRUST | |
| |$10 | 1237 925 H91 | SHELL, MAIN BEARING (.010 INCH OVERSIZE) | |
| 4 | 1238 674 H1 | BEARING, MAIN (# 2, 3, 4, 5 & 6 - UPPER) | |
| 5 | 1238 678 H1 | BEARING, MAIN (# 2, 3, 4, 5 & 6 - LOWER) | |
| 6 | 1238 683 H1 | BEARING, MAIN (# 1 & 7 - LOWER) | |
| 7 | 1238 689 H1 | BEARING, MAIN (# 1 & 7 - UPPER) | |
| 9 | 1238 666 H1 | BEARING, THRUST | |
| |$16 | 1237 926 H91 | SHELL, MAIN BEARING (.020 INCH OVERSIZE) | |
| 4 | 1238 675 H1 | BEARING, MAIN (# 2, 3, 4, 5 & 6 - UPPER) | |
| 5 | 1238 679 H1 | BEARING, MAIN (# 2, 3, 4, 5 & 6 - LOWER) | |
| 6 | 1238 684 H1 | BEARING, MAIN (# 1 & 7 - LOWER) | |
| 7 | 1238 690 H1 | BEARING, MAIN (# 1 & 7 - UPPER) | |
| 9 | 1238 666 H1 | BEARING, THRUST | |
| |$22 | 1237 927 H91 | SHELL, MAIN BEARING (.030 INCH OVERSIZE) | |
| 4 | 1238 676 H1 | BEARING, MAIN (# 2, 3, 4, 5 & 6 - UPPER) | |
| 5 | 1238 680 H1 | BEARING, MAIN (# 2, 3, 4, 5 & 6 - LOWER) | |
| 6 | 1238 685 H1 | BEARING, MAIN (# 1 & 7 - LOWER) | |
| 7 | 1238 691 H1 | BEARING, MAIN (# 1 & 7 - UPPER) | |
| 9 | 1238 666 H1 | BEARING, THRUST | |
| |$$29 | |||
| |$29 | THRUST RINGS - OVERSIZE | ||
| 9 | 1241 588 H1 | BEARING, THRUST (.010 INCH OVERSIZE) | |
| 9 | 1238 999 H1 | BEARING, THRUST (.020 INCH OVERSIZE) | |
| |$$33 | |||
| |$33 | R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED | ||
| |$34 | ASSEMBLIES CATALOG. |
