Запчасти гидравл управляющ. клапан, управляющ. клапан компоненты (/) (№99-) погрузчики колесные wa380-6 s/n 65949-up Komatsu



1 203-62-63740 Joint
2 07002-13334 O-ring
3 203-973-5750 Nipple
4 07002-13334 O-ring
5 20Y-62-23541 Elbow
6 07002-11423 O-ring
6 20Y-62-41701 Valve Assembly
7 20Y-60-22210 Body
8 20Y-60-22270 Poppet
9 701-20-61230 Spring
10 07002-11423 O-ring
11 20Y-62-47630 Nipple
12 07002-11423 O-ring
13 02896-11008 O-ring
14 02782-10212 Elbow
15 07002-11423 O-ring
16 02896-11008 O-ring
17 423-62-34190 Tube
18 07000-13035 O-ring
19 07372-21040 Bolt
20 01643-51032 Washer
21 21W-62-35820 Elbow
22 07002-11423 O-ring
22 423-62-43990 Valve Assembly
23 423-62-44110 Elbow
24 203-60-62320 Poppet
25 423-62-35310 Plug
26 02896-11009 O-ring
27 07002-11423 O-ring
28 02761-00303 Hose
29 02782-10210 Elbow
30 02896-11008 O-ring
31 07002-11423 O-ring
32 423-62-43620 Hose
33 04434-51010 Clip
34 01010-81020 Bolt
35 01643-31032 Washer
36 02781-0021D Union
37 02896-11008 O-ring
38 07002-11423 O-ring
39 423-62-43740 Hose
40 20Y-62-45710 Tee
41 07002-11423 O-ring
42 02896-11009 O-ring
43 02896-11008 O-ring
44 207-62-62460 Adapter
45 07002-11423 O-ring
46 423-62-41480 Hose
|$48 423-62-41480 Hose
|$49 423-62-41480 Hose
|$50 423-62-41480 Hose
|$51 423-62-41480 Hose
47 432-62-11520 Valve, Shuttle
|$53 432-62-11520 Valve, Shuttle
|$54 432-62-11520 Valve, Shuttle
|$55 432-62-11520 Valve, Shuttle
|$56 432-62-11520 Valve, Shuttle
35
34
33
32
31
30
29
1
2
3
4
36
37
38
39
5
6
7
8
9
10
11
12
13
47
14
15
16
17
18
19
20
40
41
42
43
44
45
28
27
26
25
24
23
22
21
46
X
