| |$0 | 6252-41-9100 | Valve Assembly | |
| 1 | 6252-41-9110 | Valve Assembly | |
| 2 | 6252-41-9120 | Case | |
| 3 | 6261-41-4810 | Seal | |
| 4 | 6261-41-4820 | Insulator | |
| 5 | 6261-41-4830 | Cover | |
| 6 | 6261-41-4840 | Plate | |
| 7 | 6261-41-4851 | Ring | |
| 8 | 6252-41-9130 | Valve | |
| 9 | 6252-41-9140 | Spring | |
| 10 | 6204-41-4510 | Seat | |
| 11 | 6204-41-4520 | Cotter | |
| 12 | 6204-41-4541 | Seal | |
| 13 | 04020-00514 | Pin, Dowel | |
| 14 | 07000-E2055 | O-Ring | |
| 15 | 702-28-21200 | Valve Assembly | |
| 16 | 01437-00820 | Bolt | |
| 17 | 6631-11-6390 | Spacer | |
| 18 | 6252-41-9160 | Plate |
