| |$1 | 6524-01-1112 | KOMATSU Diesel Particulate Filter(KDPF) Assembly | |
| |$2 | 6524-01-1111 | KOMATSU Diesel Particulate Filter(KDPF) Assembly | |
| |$3 | 6524-41-1022 | Body | |
| |$4 | 6524-41-1021 | Body | |
| 2 | 6524-41-2091 | Plate | |
| 3 | 6524-41-2112 | Plate | |
| 3 | 6524-41-2111 | Plate | |
| 5 | 6524-41-2131 | Plate | |
| 5 | 6524-41-2130 | Plate | |
| 7 | 6524-41-7030 | Mat | |
| 8 | 6524-41-2151 | Cover | |
| 10 | 6524-91-1040 | Gasket | |
| 10 | 6524-91-1010 | Clamp | |
| 11 | 6524-91-1130 | Nut | |
| 12 | 6524-91-1140 | Clamp | |
| 13 | 6524-81-1010 | Sensor Assembly | |
| 14 | 6524-91-4020 | Band | |
| 15 | 6524-81-1030 | Hose | |
| 16 | 6524-81-1020 | Hose | |
| 17 | 6520-81-1040 | Sensor | |
| 18 | 6524-91-1050 | Clip | |
| 19 | 01020-00616 | Bolt, Stainless | |
| 20 | 6524-91-1080 | Washer | |
| 21 | 6520-81-1030 | Sensor | |
| 22 | 6520-81-1030 | Sensor | |
| 23 | 6524-91-4011 | Hanger | |
| 24 | 6524-91-4020 | Band | |
| 25 | 6520-91-1020 | Clamp | |
| 26 | 6520-91-1030 | Gasket | |
| 27 | 6755-11-5130 | Joint |
