Запчасти стартер погрузчики с бортовым поворотом sk05j-2 s/n sk05jf20001-up Komatsu



\0 871070033 ENGINE, ASSY.
1 YM129400-77012 STARTER MOTOR
2 YM129486-77400 ROTOR
3 YM171008-77410 BEARING
4 YM171008-77420 BEARING
5 YM129400-77441 COIL ASSY.,FIELD
6 YM129486-77460 BRUSH, ASSY.
7 YM129486-77470 HOLDER BRUSH, ASSY.
8 YM129486-77460 BRUSH, ASSY.
9 YM129486-77490 SPRING
10 YM129900-77460 COVER, REAR
11 YM171008-77510 HOUSING, GEAR
12 YM129400-77520 HOUSING, GEAR
13 YM129400-77531 SWITCH, MAGNETIC
14 YM171008-77540 LEVER SET, SHIFT
17 YM129400-77571 COVER DUST PAN, ASSY.
18 YM129900-77640 BOLT
19 YM171008-77650 PINION
20 YM171008-77660 SHAFT
21 YM171008-77670 KIT, STOP SET, PINION
25 YMX2114555500 CLUTCH, STARTER
26 YMX2114955020 BEARING
27 YMX2240410100 BEARING
28 YM26106-060322 SCREW
29 YM26106-060402 SCREW
30 YM26116-120252 BOLT PLATED
A
A
A
17
14
1
17
30
12
13
28
17
11
29
26
21
27
25
19
18
20
10
6
3
5
4
2
9
8
7
X
