Запчасти гидр. бак., бак (№7-) экскаваторы pc450lc-8r s/n 75001-up Komatsu



1 208-60-75111 Tank
1 208-60-75110 Tank
2 203-60-31100 Elbow Assembly
3 203-60-31160 Tube
4 07044-12412 Plug
5 07002-12434 O-ring
6 207-62-72171 Elbow
7 07002-12434 O-ring
8 02896-11018 O-ring
9 02782-10522 Elbow
10 07002-12434 O-ring
11 02896-11015 O-ring
12 02782-10315 Elbow
13 07002-12034 O-ring
14 02896-11009 O-ring
15 207-62-72110 Union
16 07002-13334 O-ring
17 207-62-64740 O-ring
18 02782-10422 Elbow
19 07002-12034 O-ring
20 02896-11012 O-ring
21 02783-10210 Elbow
22 07002-11423 O-ring
23 02896-11008 O-ring
24 208-60-71123 Element, Transmission Oil Filter
25 07069-25400 Strainer
26 208-60-71160 Valve Assembly
27 07069-34075 Spring
28 208-60-71130 Plate
29 07000-15210 O-ring
30 01010-81225 Bolt
31 01643-31232 Washer
|$32 208-60-71140 Strainer Assembly
32 208-60-71150 Rod Assembly
33 12R-60-11230 Spring
34 20Y-60-21320 Holder
35 22B-60-11160 Strainer
36 208-60-61190 Cover
37 07000-15180 O-ring
38 01010-81225 Bolt
39 01643-31232 Washer
2
3
23
22
21
20
19
18
17
16
15
2
8
10
9
6
1
5
4
39
38
37
36
35
33
34
32
31
30
29
28
27
26
25
24
7
12
13
14
11
