| 1 | 208-01-71111 | Bracket | |
| 2 | 01010-81085 | Bolt | |
| 3 | 01643-31032 | Washer | |
| 4 | 6167-21-5910 | Spacer | |
| 5 | 01011-81005 | Bolt | |
| 6 | 01643-31032 | Washer | |
| 7 | 207-01-35140 | Cushion | |
| 8 | 207-01-61170 | Stopper | |
| 9 | 208-01-11161 | Washer | |
| 10 | 208-01-11181 | Bolt | |
| 11 | 01580-12419 | Nut | |
| 11 | 01580-02419 | Nut | |
| 12 | 01643-32460 | Washer | |
| 13 | 208-01-71120 | Bracket | |
| 14 | 01010-81650 | Bolt | |
| 14 | 01010-61650 | Bolt | |
| 15 | 01643-31645 | Washer | |
| 16 | 04020-01228 | Pin, Dowel | |
| 17 | 207-01-35140 | Cushion | |
| 18 | 207-01-61170 | Stopper | |
| 19 | 208-01-11161 | Washer | |
| 20 | 208-01-11181 | Bolt | |
| 21 | 01580-12419 | Nut | |
| 21 | 01580-02419 | Nut | |
| 22 | 01643-32460 | Washer | |
| 23 | 07260-20950 | Hose | |
| 24 | 07285-00155 | Clip |
