| |$0 | 600-825-6150 | Alternator | |
| 1 | KD0-35100-0300 | Rotor Assembly | |
| 2 | KD1-33923-0790 | Collar | |
| 3 | KD0-35923-0160 | Collar | |
| 4 | KD0-09201-0980 | Bearing, Ball | |
| 5 | KD0-35200-0460 | Stator Assembly | |
| 6 | KD0-35300-0350 | Bracket Assembly | |
| 7 | KD0-09201-1140 | Bearing, Ball | |
| 8 | KD0-35926-0070 | Retainer | |
| 9 | KD0-35951-0060 | Packing | |
| 10 | KD0-35926-0090 | Retainer | |
| 11 | KD1-33926-0730 | Retainer | |
| 12 | KD0-0275-06802 | Bolt | |
| 13 | KD0-35411-0560 | Pulley | |
| 14 | KD0-35421-0240 | Fan | |
| 15 | KD1-0330-16012 | Washer | |
| 16 | KD1-0335-16002 | Washer, Spring | |
| 17 | KD0-0280-16022 | Nut | |
| 18 | KD0-35120-0290 | Coil, Field | |
| 18 | KD0-35700-0920 | Bracket Assembly | |
| 19 | KD0-35710-1010 | Bracket | |
| 20 | KD0-35730-0700 | Rectifier Assembly | |
| 21 | KD0-09170-2501 | Condenser | |
| 22 | KD0-35943-0140 | Bushing | |
| 23 | KD0-35943-0150 | Bushing | |
| 24 | KD0-35943-0160 | Bushing | |
| 25 | KD0-35943-0170 | Bushing | |
| 26 | KD0-35923-0130 | Collar | |
| 27 | KD0-35784-0210 | Bar, Connect | |
| 28 | KD0-35784-0290 | Bar, Plate | |
| 29 | KD0-09057-0220 | Washer | |
| 30 | KD7-35719-0211 | Regulator Assembly | |
| 31 | KD0-35761-0250 | Cover |
