| 1 | 421-07-11550 | Clip | |
| 2 | 01010-81225 | Bolt | |
| 3 | 01643-31232 | Washer | |
| 4 | 20Y-810-1170 | Clip | |
| 5 | 421-07-11550 | Clip | |
| 6 | 22S-62-26210 | Spacer | |
| 7 | 01011-81210 | Bolt | |
| 8 | 01643-31232 | Washer | |
| 9 | 20Y-810-1170 | Clip | |
| 10 | 141-06-11220 | Clip | |
| 11 | 195-61-21440 | Spacer | |
| 12 | 01011-81290 | Bolt | |
| 13 | 01643-31232 | Washer | |
| 14 | 2A5-979-1470 | Clip | |
| 15 | 141-06-11220 | Clip | |
| 16 | 2A5-979-1470 | Clip | |
| 17 | 141-06-11220 | Clip | |
| 18 | 01010-81225 | Bolt | |
| 19 | 01643-31232 | Washer | |
| 20 | 20Y-810-1170 | Clip | |
| 21 | 195-33-11220 | Spacer | |
| 22 | 01010-81250 | Bolt | |
| 23 | 01643-31232 | Washer | |
| 24 | 141-06-11220 | Clip | |
| 25 | 195-33-11220 | Spacer | |
| 26 | 01010-81250 | Bolt | |
| 27 | 01643-31232 | Washer | |
| 28 | 04120-21760 | V-Belt |
