Запчасти кабина (/8) экскаваторы pc27mr-2 s/n f00103-up Komatsu



\0 22M-54-R0061 OPERATOR'S CAB, ASSY.
\0 22M-54-00070 DOOR, ASSY.
1 20Y-54-14520 LOCK, ASSY.
2 01435-00612 BOLT
3 205-54-71840 CLAMP
4 20Y-54-14520 LOCK, ASSY.
5 01010-80616 BOLT
6 01643-30623 WASHER
7 22M-54-24450 HOUSING
8 01435-40610 BOLT
9 22B-54-16220 HANDLE
10 01023-70612 SCREW
11 22B-54-16211 HANDLE
12 01435-00610 BOLT
13 20Y-54-35890 LOCK, ASSY.
14 22M-54-14650 LEVER, ASSY.
15 01435-00612 BOLT
16 22M-54-14661 LEVER, ASSY.
17 01435-00610 BOLT
18 22M-54-24320 TIE-ROD
19 22M-54-24330 TIE-ROD
20 22M-54-24340 TIE-ROD
21 22M-54-24351 TIE-ROD
22 22M-54-24360 TIE-ROD
23 22M-54-24370 TIE-ROD
24 205-54-71830 CLAMP
5
6
4
2
3
1
20
16
19
24
24
21
17
3
24
3
15
18
9
14
24
3
23
3
22
8
10
7
13
12
11
a
a
b
b
c
c
d
d
e
e
X
