| 1 | 2942109M91 | LAMP | |
| 2 | 2942110M91 | LAMP | |
| 3 | 1443697X1 | BULB | |
| 4 | 2904890M91 | BRACKET | |
| 5 | 390974X1 | DISC | |
| 6 | 3007514X1 | NUT | |
| 7 | 2999999M1 | SPOUT | |
| 8 | 339124X1 | SCREW | |
| 9 | 1443789X1 | SPRING WASHER | |
| 10 | 2904714M1 | COVERING | |
| 11 | 339230X1 | SCREW | |
| 12 | 1443791X1 | SPRING WASHER | |
| 13 | 2904951M91 | LIGHT | |
| 15 | 2962708M1 | GASKET | |
| 16 | 1443998X1 | BULB | |
| 17 | 1444290X1 | SCREW | |
| 18 | 391074X1 | SCREW | |
| 19 | 2904826M1 | RUBBER SOCKET | |
| 20 | 4020782M1 | DISTANCE PIECE | |
| 21 | 2942118M91 | INSET | |
| 22 | 2942089M1 | RETAINER | |
| 23 | 2942065M1 | DIFFUSING LENS | |
| 24 | 2942092M1 | SPRING | |
| 25 | 2942090M1 | GASKET | |
| 26 | 2942091M1 | REFLECTOR | |
| 27 | 2942093M1 | LAMP SOCKET |
