| 1 | 4000915M91 | FUEL TANK | |
| 2 | 2876009M1 | TANK CAP | |
| 2A | 2963928M91 | TANK CAP | |
| 3 | 1444633X1 | SEAL | |
| 4 | 2949025M91 | STRAINER | |
| 5 | 3063868M8 | ANGLE | |
| 6 | 339401X1 | SCREW | |
| 7 | 390734X1 | PLAIN WASHER | |
| 8 | 1443790X1 | SPRING WASHER | |
| 9 | 339402X1 | NUT | |
| 10 | 1443796X1 | SPRING WASHER | |
| 11 | 391421X1 | SCREW | |
| 12 | 2904561M91 | BALL VALVE | |
| 13 | 2904531M1 | STUD | |
| 14 | 2976298M91 | PIPE | |
| 15 | 2999610M1 | BANJO BOLT | |
| 16 | 390839X1 | SEAL | |
| 17 | 2951329M1 | CLIP | |
| 18 | 339560X1 | SCREW | |
| 19 | 1443791X1 | SPRING WASHER | |
| 20 | 339030X1 | NUT | |
| 21 | 2995431X1 | HOSE | |
| 22 | 2995450X1 | HOSE | |
| 23 | 2999722M1 | BANJO FITTING | |
| 24 | 3005069X1 | CLIP | |
| 25 | 390839X1 | SEAL | |
| 26 | 1444759X1 | BANJO BOLT | |
| 27 | 1443790X1 | SPRING WASHER | |
| 28 | 339401X1 | SCREW | |
| 29 | 2870206M91 | PRE FILTER | |
| 30 | 2992582M91 | PRE FILTER | |
| 31 | 2999610M1 | BANJO BOLT | |
| 32 | 390839X1 | SEAL | |
| 33 | 2992614M91 | BANJO FITTING | |
| 34 | 3005643X1 | PLUG | |
| 35 | 391312X1 | SEAL | |
| 36 | 1444251X1 | PLUG | |
| 39 | 2866877M1 | BANJO BOLT | |
| 40 | 3063877M8 | PIPE | |
| 41 | 2938393M1 | STRAP | |
| 42 | 2944883M1 | CLIP | |
| 43 | 339287X1 | SCREW | |
| 44 | 1443789X1 | SPRING WASHER | |
| 45 | 339169X1 | NUT |
