Запчасти впрыск система, up - двигатель no. бульдозеры гусеничные l700d turbo/super s/n 331310001 - up Komatsu

ТОПЛИВН. НАСОС


1 3086060M91 INJECTION PUMP
1B 3086093M1 AIR FILTER
1C 3086094M1 STUD
2 2868360M1 PRIMING PUMP
2A 2871867M1 GASKET
3 1443809X1 WOODRUFF KEY
4 1443792X1 SPRING WASHER
5 3067709M8 NUT
6 2871855M1 LEVER
7 1443791X1 SPRING WASHER
8 339666X1 SCREW
9A 2872805M91 OVERFLOW OIL LINE
9B 3086064M91 PIPE
10 1440993X1 SEAL
11 2999617M1 BANJO BOLT
12 339132X1 SCREW
13 1443776X1 DISC
14 2872777M1 CARRIER
15 339139X1 SCREW
16 1443792X1 SPRING WASHER
17 2872841M91 INJECTION PIPE
18 2872842M91 INJECTION PIPE
19 2872843M91 INJECTION PIPE
20 2872844M91 INJECTION PIPE
21 2872845M91 INJECTION PIPE
22 2872846M91 INJECTION PIPE
23 2872815M1 HOLDING CLAMP
24 2872816M1 HOLDING CLAMP
25 2872819M1 HOLDING CLAMP
26 2872820M1 HOLDING CLAMP
27 2870620M1 HOLDING CLAMP
28 2870621M1 HOLDING CLAMP
29 2870619M1 PROTECTOR
30 391074X1 SCREW
31 1443791X1 SPRING WASHER
32 339030X1 NUT
33 2872256M91 VALVE
34 2872251M1 FUEL INJECTOR
35 2871009M1 BOXNUT
36 2871008M1 SEAL
37 2862385M1 CAP
38 2871504M1 HOSE
39 2871516M1 HOSE
40 1444656X1 CLIP
41 1444075X1 SCREW
42 1443798X1 SPRING WASHER
43 392289X1 NUT
44 3086051M1 HOSE ASSEMBLY
45 2999610M1 BANJO BOLT
46 390839X1 SEAL
47 1441937X91 UNION
48 1444689X1 OLIVE
49 1442015X1 BOXNUT
50 1444756X1 BANJO BOLT
39
1B
1C
22
9A
41
2A
38
9B
40
1
42
1A
43
21
38
20
38
30
29
19
31
32
28
38
27
18
30
26
29
17
25
38
31
32
30
37
24
35
23
51
29
52
12
33
31
32
34
13
6
36
47
11
7
8
48
10
49
3
4
10
5
11
14
9
2
46
16
15
45
44
10
50
