| 0 | 2986799M91 | COOLER | |
| 1 | 3254085M91 | RADIATOR BLOCK | |
| 2 | 3254088M91 | EXPANSION TANK | |
| 2A | 3232401M1 | FILLER | |
| 2B | 3232402M1 | GASKET | |
| 3 | 2995266X1 | COVER | |
| 4 | 3254087M91 | FRAME | |
| 5 | 2977938M91 | HOSE | |
| 6 | 2994668M1 | CLIP | |
| 7 | 3007698X1 | HOSE | |
| 8 | 1444845X1 | CLIP | |
| 9 | 1442936X1 | SEAL | |
| 10 | 390247X1 | SCREW | |
| 11 | 391039X1 | PLAIN WASHER | |
| 12 | 339123X1 | SCREW |
