Запчасти приводrs сиденье бульдозеры гусеничные d670e s/n 336650051- up; d680e s/n 336620051 - up Komatsu



1 4101938M91 SEAT
2 4101939M91 SEAT
3 3252484M91 BACK REST
4 3252498M91 BACK REST
5 4908568M91 SEAT CUSHION
6 3252499M91 SEAT CUSHION
7 4909918M91 BOTTOM PART
8 3005720X1 SCREW
9 339124X1 SCREW
10 3252487M1 COVERING
11 339123X1 SCREW
12 2993792X1 SPRING WASHER
17 3252490M1 GRIP
18 3252491M1 GRIP
19 3252492M1 GRIP
20 3252493M91 GRIP
21 391566X1 SLEEVE
22 4909919M91 DAMPER
23 339010X1 SCREW
24 3252478M1 TUBE
25 1444329X1 NUT
26 3252479M1 TENSION SPRING
27 4909913M91 RAIL
28 4909912M91 RAIL
29 1442324X1 SCREW
30 4909920M1 STIRRUP
31 4909915M1 SPRING
32 4909916M1 SPRING
33 3008354X1 SAFETY CATCH
34 4202972M91 SAFETY BELT
35 339168X1 SCREW
36 3073369M1 DISC
37 3067846M8 PLAIN WASHER
37
19
3
4
24
2
1
10
9
10
13
14
23
5
6
22
12
1
1
28
15
16
25
18
17
26
21
7
20
8
32
12
27
29
33
31
11
12
34
30
36
12
35
