Запчасти картер маховика погрузчики колесные wa320-5 s/n wa320-5h50051 - up Komatsu



1 6738-22-4710 SPACER, MOUNTING
2 6732-11-1920 PLUG
|$4 6732-11-1910 PLUG
3 6738-22-5110 BRACKET
|$6 6301-11-4630 BRACKET
4 6732-21-4161 O-RING
5 6738-22-4110 BOLT
|$10 6732-21-4290 BOLT
|$11 6738-22-4110 BOLT
|$12 6732-21-4290 BOLT
6 6735-21-4191 GASKET, REAR COVER
7 6732-21-4120 BOLT
|$15 6732-21-5160 BOLT
|$16 6732-21-4120 BOLT
8 6732-21-5160 BOLT
|$18 6735-21-4120 BOLT
9 6732-21-4130 COVER
10 6732-21-4150 PLUG
11 6735-K2-3010 SEAL, OIL (KIT)
|$23 6735-K2-3001 SEAL, OIL (KIT)
|$24 6735-K2-3010 SEAL, OIL (KIT)
|$25 6735-K2-3001 SEAL, OIL (KIT)
|$26 6735-K2-3010 SEAL, OIL (KIT)
|$27 6735-K2-3001 SEAL, OIL (KIT)
12 6731-21-6231 COVER, REAR
|$29 6732-21-4220 COVER, REAR
|$30 6731-21-6231 COVER, REAR
13 6732-22-4170 SEAL, RECTANGULAR
14 6732-21-4220 BOLT
15 6735-21-4250 CLIP
16 6732-22-4210 HOUSING, FLYWHEEL
|$35 6732-21-4232 HOUSING, FLYWHEEL
17 6742-01-5158 GASKET, COVER PLATE
18 6735-61-2140 PLUG
|$38 6735-21-4170 PLUG
|$40 6732-21-5170 O-RING
|$42 6735-21-4160 O-RING
20 09920-00150 LIQUID GASKET, LG-7, 150G
14
16
20
18
19
1
3
8
13
11
12
6
2
4
10
17
9
15
5
7
