| |$1 | 419-850-H200 | Boom Assembly | |
| 2 | 419-70-21810 | Bushing | |
| 3 | 419-70-31810 | Bushing | |
| 4 | 419-70-11890 | Bushing | |
| 5 | 419-09-11110 | Seal, Dust | |
| 6 | 424-09-12320 | Seal, Dust | |
| |$8 | 419-70-H1180 | Bellcrank | |
| 8 | 419-70-31870 | Bushing | |
| 9 | 421-09-11320 | Seal, Dust | |
| |$12 | 419-850-H101 | Link Assembly | |
| 11 | 419-70-11820 | Bushing | |
| 12 | 419-09-11110 | Seal, Dust | |
| 13 | 419-70-31220 | Pin | |
| 14 | 419-70-11460 | Shim, T=1.5mm | |
| 14 | 419-70-11470 | Shim, T=3.0mm | |
| 14 | 20S-70-21470 | Spacer, T=1.0mm | |
| 15 | 01010-81625 | Bolt | |
| 16 | 421-70-11280 | Washer | |
| 17 | 419-70-31921 | Pin | |
| 18 | 419-70-11420 | Shim, T=1.5mm | |
| 18 | 419-70-11430 | Shim, T=3.0mm | |
| 20 | 419-70-11410 | O-Ring | |
| 21 | 419-70-11490 | Bolt | |
| 22 | 01596-00606 | Nut | |
| 23 | 01641-20608 | Washer | |
| 24 | 01010-81625 | Bolt | |
| 25 | 421-70-11280 | Washer | |
| 26 | 419-70-31960 | Pin | |
| 27 | 01010-81630 | Bolt | |
| 28 | 421-70-11280 | Washer |
