Запчасти капот погрузчики с бортовым поворотом sk1020-5 turbo usa s/n 37ctf00003-up Komatsu



1 37B-54-11312 HOOD, ENGINE, ASSY.
2 37B-54-11112 HOOD, ENGINE
3 37B-54-11222 SHEET
4 37B-54-11320 GUARD GRATING
5 37A-09-25038 SCREW
6 37B-54-11241 FRAME
7 01640-20816 WASHER
8 01252-70830 SCREW
9 01240-00830 SCREW
10 21D-09-24408 NUT
11 37A-54-11250 SUPPORT
12 37A-09-1T666 SCREW
13 3F0540602 BOOT
14 37A-54-11260 GASKET
15 37B-54-11270 GASKET
16 37A-54-11280 WASHER
17 01016-50840 BOLT
18 01643-10823 WASHER
19 21D-09-24408 NUT
20 816215043 LOCK, ASSY.
21 37A-54-12100 PUSH-BUTTON, ASSY.
22 802090228 WASHER
23 802148004 WASHER
24 37A-54-11171 HINGE
25 801015108 BOLT
26 802170002 WASHER
27 37A-54-11210 PIPE
28 801085029 BOLT
29 801920104 NUT
30 802148009 WASHER
31 37B-54-11210 DAMPER
32 801852408 NUT, STOP
33 37A-54-11320 SUPPORT
34 801852210 NUT, STOP
35 37B-54-15350 STOPPER
36 332205627 SPACER
13
B
27
D
28
A
C
C
A
B
D
11
17
12
20
3
21
18
22
33
36
19
35
32
31
1
32
30
29
6
36
33
6
8
7
4
24
23
2
5
26
16
34
9
25
26
14
10
15
X
