Запчасти капот погрузчики с бортовым поворотом sk820-5 s/n 37btf50112-up Komatsu



1 37B-54-11312 ENGINE HOOD, ASSEMBLY
2 37B-54-11112 ENGINE HOOD
3 37B-54-11222 PANEL
4 37B-54-11320 NET
5 37A-09-25038 SCREW
6 37B-54-11241 FRAME
7 01640-20816 WASHER
8 01252-70830 BOLT, HEXAGON SOCKET HEAD
9 01240-00830 SCREW
10 21D-09-24408 NUT
11 37A-54-11250 SUPPORT
12 37A-09-1T666 BOLT
13 20M-54-R2250 CASE
14 37A-54-11260 GASKET
15 37B-54-11270 GASKET
16 01640-20816 WASHER
17 37A-54-11280 WASHER
18 01016-50840 BOLT
19 01643-10823 WASHER
20 21D-09-24408 NUT
21 37A-54-11290 CATCH
22 37A-54-12100 PUSH-BUTTON, ASSEMBLY
23 21D-09-73228 WASHER
24 37A-54-11171 HINGE
25 01010-81020 BOLT
26 01598-01011 NUT
27 01643-11032 WASHER
28 37A-01-11660 SILENCER
29 01435-00830 BOLT
30 01580-10806 NUT
31 37A-09-4A009 WASHER
32 37B-54-11210 GAS SPRING
33 332205627 SPACER
34 01643-10823 WASHER
35 22E-09-13330 NUT
36 37B-54-15300 STOPPER
37 37B-54-15310 BUSHING
38 37A-09-4G007 WASHER
39 37A-54-11320 SUPPORT
40 01010-81020 BOLT
41 01643-11032 WASHER
29
28
13
22
11
18
12
23
21
3
33
34
35
19
20
32
31
30
36
1
40
41
39
35
34
6
6
8
7
4
37
38
5
2
24
17
27
14
9
26
16
10
25
15
27
a
b
d
c
c
d
b
a
