| |$0 | 207-70-K3213 | Arm Assembly | |
| 1 | Arm | ||
| 2 | 206-62-K2740 | Bracket, Welded | |
| 3 | 207-970-5380 | Bracket, Welded | |
| 4 | 20J-70-12180 | Seat, Welded | |
| 5 | 20Y-70-K6410 | Seat, Welded | |
| 6 | 20Y-62-K7290 | Seat, Welded | |
| 7 | 207-70-K3330 | Seat, Welded | |
| 8 | 207-70-K4360 | Pipe, Welded | |
| 9 | 207-970-5420 | Bracket, Welded | |
| 10 | 207-70-72341 | Bushing | |
| 11 | 207-70-33160 | Bushing | |
| 12 | 207-70-72460 | Bushing | |
| 13 | 707-H1-X0710 | Cylinder Assembly |
