| 1 | 01010-81225 | Bolt | |
| 2 | 01643-31232 | Washer | |
| 3 | 04434-52112 | Clip | |
| 4 | 01010-81225 | Bolt | |
| 5 | 01643-31232 | Washer | |
| 6 | 207-979-6180 | Bracket | |
| 7 | 01010-81225 | Bolt | |
| 8 | 01643-31232 | Washer | |
| 9 | 04434-52112 | Clip | |
| 10 | 01010-81225 | Bolt | |
| 11 | 01643-31232 | Washer | |
| 12 | 08057-22012 | Clip | |
| 13 | 01010-81225 | Bolt | |
| 14 | 01643-31232 | Washer | |
| 15 | 08057-12012 | Clip | |
| 16 | 581-22-12760 | Spacer | |
| 17 | 01010-81270 | Bolt | |
| 18 | 01643-31232 | Washer | |
| 19 | 04434-53212 | Clip | |
| 20 | 07095-40523 | Cushion | |
| 21 | 01010-81225 | Bolt | |
| 22 | 01643-31232 | Washer | |
| 23 | 01643-31232 | Washer | |
| 24 | 195-979-3570 | Collar | |
| 25 | 07095-40523 | Cushion | |
| 26 | 04434-53212 | Clip | |
| 27 | 01011-81200 | Bolt | |
| 28 | 2A5-06-11990 | Cap | |
| 29 | 08028-44035 | Cable, Ground | |
| 30 | 01010-81025 | Bolt | |
| 31 | 01643-31032 | Washer | |
| 32 | 01010-81020 | Bolt | |
| 33 | 01643-31032 | Washer |
