| 1 | 417-06-23212 | HEAD LAMP ASS'Y | |
| |$2 | 417-06-23221 | BULB.62/62W | |
| |$3 | 417-06-23260 | LENS | |
| |$4 | 08056-00371 | CONNECTOR | |
| 2 | 41G-06-13201 | LAMP ASS'Y COMBINATION | |
| |$6 | 41G-06-13230 | BULB,5W | |
| |$7 | 08105-12420 | BULB,2.5W | |
| |$8 | 41G-06-13210 | LENS FRONT | |
| |$9 | 41G-06-13220 | LENS REAR | |
| |$10 | 01220-40425 | SCREW | |
| |$11 | 08021-00400 | CONNECTOR | |
| |$12 | 08022-04001 | CONNECTOR | |
| 3 | 421-06-Z0110 | SUPPORT L.H | |
| 4 | 421-06-Z0120 | SUPPORT R.H | |
| 5 | 01435-01020 | BOLT | |
| 6 | 01435-01225 | BOLT | |
| 7 | 423-06-Z8111 | COVER R.H | |
| 8 | 417-06-12560 | GROMMET | |
| 9 | 423-06-Z7111 | COVER L.H |
