Запчасти стартер (7.kw)(№8-) двигатели sa6d110-1j s/n 50202-up Komatsu



|$0 600-813-4650 STARTING MOTOR ASS'Y,(7.5KW)
1 KD7-23320-0060 SHIFT LEVER ASS'Y
2 KD0-47100-3940 MAGNETIC SWITCH A.
3 KD0-25000-6890 SWITCH ASS'Y
4 KD1-0240-08405 BOLT
5 KD1-23785-0060 LEAD WIRE ASS'Y
6 KD7-23780-0200 TERMINAL ASS'Y
|$8 KD7-23700-0520 REAR BRACKET ASS'Y
7 KD0-23740-0250 BRUSH ASS'Y
8 KD1-23913-0040 SPRING,BRUSH
9 KD0-23750-0250 BRUSH HOLDER ASS'Y
10 KD0-23700-0130 REAR BRACKET ASS'Y
11 KD0-23901-0170 BOLT
12 KD0-23600-0230 CENTER BRACKET A.
13 KD7-23120-0310 SHAFT ASS'Y
14 KD1-0454-60067 BEARING,BALL
15 KD0-23611-0690 BRACKET,CENTER
16 KD0-23310-0740 FRONT BRACKET A.
17 KD7-23351-0080 METAL
18 KD1-23914-0020 RING,CLIP
19 KD1-23181-0020 STOPPER,PINION
20 KD1-23500-0190 CLUTCH ASS'Y,OVER RUNNING
21 KD7-23100-0310 ARMATURE ASS'Y
22 KD1-0454-62047 BEARING,BALL
23 KD1-0454-62007 BEARING,BALL
24 KD0-23230-0281 FIELD COIL ASS'Y
25 KD7-23920-0100 WASHER ASS'Y,(NOT SHOWN)
26 KD7-09210-1600 SEAL ASS'Y,(NOT SHOWN)
1
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
X
