Запчасти блок цилиндров двигатели sa6d170-b-1f-sp s/n 11763-up Komatsu



|1 6162-23-1103 CYLINDER BLOCK ASS'Y
1 BLOCK,CYLINDER
2 6162-23-1490 BUSHING,CAM
3 6162-23-1210 CAP,MAIN METAL¤ NO.1¤2¤3¤4¤5¤7
4 6162-23-1250 CAP,MAIN METAL¤ NO.6
5 6162-23-1260 PIN,DOWEL
6 6162-23-1710 BOLT,MAIN CAP
7 6127-21-1741 WASHER
8 04020-00514 PIN,DOWEL
9 07043-50415 PLUG
10 07046-43516 PLUG
11 07043-50211 PLUG
12 07043-50108 PLUG
13 07043-00108 PLUG
14 07046-48020 PLUG
15 07040-11409 PLUG
16 07005-01412 GASKET (K2)
17 07040-11007 PLUG
18 07005-01012 GASKET (K2)
19 04020-01434 PIN,DOWEL
20 6127-21-1160 PIN,DOWEL
21 6162-13-1410 PIN
22 6162-23-1140 TUBE,OIL TRANSFER
23 04020-00820 PIN,DOWEL
24 6162-23-2210 LINER,CYLINDER
25 6162-23-2250 SEAL,CLEVIS (K2)
26 6162-23-2220 O-RING,CENTER (K2)
27 6162-23-2240 O-RING,LOWER (K2)
28 6161-21-1840 NOZZLE,PISTON COOLING
29 6100-21-1130 PLUG
30 07043-70108 PLUG,PISTON COOLING
31 07000-62016 O-RING (K2)
32 01010-30818 BOLT
33 01602-00825 WASHER,SPRING
34 6162-23-6510 PLATE
35 6162-23-6521 GASKET (K2)
36 01010-31030 BOLT
37 01602-01030 WASHER,SPRING
38 7861-99-1300 SENSOR,OIL PRESSURE
38A 600-050-2620 CLIP
39 6162-23-6530 PLATE
40 6127-51-6822 GASKET (K2)
41 01010-31025 BOLT
42 01602-01030 WASHER,SPRING
43 09605-01430 PLATE¤ NAME,(LIMITED SUPPLY)
44 04418-02550 SCREW
1
1
2
3
4
5
5
6
6
7
7
8
8
9
9
10
10
11
12
12
12
12
12
12
12
12
13
14
15
15
16
16
17
18
19
19
20
21
22
23
24
25
26
27
28
28
29
30
31
31
32
32
33
33
34
35
36
36
37
37
38
38A
39
40
41
42
43
44
