| 1 | 6162-73-4630 | JOINT | |
| 2 | 07043-50108 | PLUG | |
| 3 | 01010-31025 | BOLT | |
| 4 | 01643-31032 | WASHER | |
| 5 | 6150-71-5480 | HOSE | |
| 6 | 07271-11465 | HOSE | |
| 7 | 07206-31014 | BOLT,JOINT | |
| 8 | 07005-01412 | GASKET (K2) | |
| 9 | 04434-51810 | CLIP | |
| 10 | 6138-81-8660 | SPACER | |
| 11 | 01010-30865 | BOLT | |
| 12 | 01602-00825 | WASHER,SPRING | |
| 13 | 01640-00816 | WASHER | |
| 14 | 6134-11-5120 | SPACER | |
| 15 | 6164-61-7170 | BOLT | |
| 16 | 01643-31032 | WASHER | |
| 17 | 6150-65-7440 | STAY | |
| 18 | 01010-31060 | BOLT | |
| 19 | 01602-01030 | WASHER,SPRING | |
| 20 | 01640-01016 | WASHER | |
| 21 | 04434-51810 | CLIP | |
| 22 | 01010-31020 | BOLT | |
| 23 | 01580-01008 | NUT | |
| 24 | 01643-31032 | WASHER | |
| 25 | 6128-71-1932 | JOINT | |
| 26 | 07206-31014 | BOLT,JOINT | |
| 27 | 07005-01412 | GASKET (K2) |
