Запчасти головка цилиндров генераторы дизельные eg125bs-2 s/n 4501-up Komatsu



|1 6137-12-1020 CYLINDER HEAD ASS'Y,WITH VALVE
|1 6137-12-1200 CYLINDER HEAD ASS'Y,VALVE LESS
1 HEAD,CYLINDER
2 6136-11-1130 SLEEVE,HOLDER
3 6138-12-1310 SEAT,INTAKE VALVE (STD)
|3 6138-19-1310 SEAT¤ 0.25MM,INTAKE VALVE (OS)
|3 6138-18-1310 SEAT¤ 0.50MM,INTAKE VALVE (OS)
|3 6138-17-1310 SEAT¤ 0.75MM,INTAKE VALVE (OS)
|3 6138-16-1310 SEAT¤ 1.00MM,INTAKE VALVE (OS)
4 6136-12-1320 SEAT,EXHAUST VALVE (STD)
|4 6136-19-1420 SEAT¤ 0.25MM,EXHAUST VALVE (OS)
|4 6136-18-1420 SEAT¤ 0.50MM,EXHAUST VALVE (OS)
|4 6136-17-1420 SEAT¤ 0.75MM,EXHAUST VALVE (OS)
|4 6136-16-1420 SEAT¤ 1.00MM,EXHAUST VALVE (OS)
5 6136-19-1430 GUIDE,VALVE
6 07046-42816 PLUG
7 07046-44016 PLUG
8 07043-50108 PLUG
9 6138-42-4110 VALVE,INTAKE
10 6136-42-4210 VALVE,EXHAUST
11 6136-42-4410 SPRING,VALVE
12 6136-42-4510 GUIDE,SPRING
13 6136-42-4520 COTTER,VALVE
14 6136-41-4530 SEAT,SPRING
15 6136-11-1813 GASKET,HEAD (K1)
|15 6136-11-1812 GASKET,HEAD (K1)
16 6136-12-1610 BOLT
17 6136-11-1910 HANGER,FRONT
18 6136-11-1821 GASKET (K1)
19 6136-11-1930 HANGER,REAR
20 01010-31025 BOLT
21 01602-01030 WASHER,SPRING
1
2
3
4
5
5
6
7
8
8
9
10
11
11
12
12
13
13
14
14
15
16
17
18
19
20
21
