| 1 | 6643-51-9611 | HOSE,MAIN SUCTION | |
| 2 | 6679-51-9611 | HOSE,SCAVENGING | |
| 3 | 6643-51-9221 | HOSE,AERATOR | |
| 3 | 6643-51-9220 | PIPE,AERATOR | |
| 4 | 6600-01-3262 | ELBOW | |
| 4 | 6600-01-3220 | ELBOW | |
| 5 | 6600-01-3710 | NIPPLE | |
| 6 | 6679-51-9312 | HOSE | |
| 7 | 6679-51-9412 | HOSE | |
| 8 | 02701-31006 | ELBOW | |
| 9 | 6600-01-3242 | ELBOW | |
| 9 | 6600-01-3241 | ELBOW | |
| 9 | 6600-01-3240 | ELBOW | |
| 10 | 6600-01-3770 | CONNECTOR | |
| 11 | 6600-01-3810 | CONNECTOR | |
| 12 | 6610-21-5670 | GASKET (K3) | |
| 13 | 02030-20625 | BOLT | |
| 14 | 02310-11224 | WASHER,SPRING | |
| 15 | 6610-81-8820 | ELBOW | |
| 16 | 6600-01-5710 | CLAMP | |
| 17 | 01010-30616 | BOLT | |
| 18 | 01602-00619 | WASHER,SPRING | |
| 19 | 01580-00605 | NUT | |
| 20 | 6600-01-3791 | CONNECTOR | |
| 20 | 6600-01-3790 | CONNECTOR | |
| 21 | 6679-51-9952 | PIPE | |
| 21 | 6679-51-9951 | PIPE | |
| 21 | 6679-51-9950 | PIPE | |
| 22 | 6679-51-9960 | PIPE | |
| 23 | 6679-51-9930 | CLAMP | |
| 24 | 6675-51-9581 | CLAMP | |
| 25 | 01050-31020 | BOLT | |
| 26 | 01602-01030 | WASHER,SPRING | |
| 27 | 6600-01-5722 | CLAMP | |
| 27 | 6600-01-5720 | CLAMP | |
| 28 | 01641-21223 | WASHER |
