Запчасти горный тормоз (внутр. части)(№-) самосвалы hd985-5 s/n 1021-up Komatsu
|
|
|$1 |
6212-11-8102 |
EXHAUST BRAKE ASS'Y
|
|
|
|$3 |
JKX8087-061 |
BRAKE VALVE ASS'Y
|
|
|
1 |
|
BODY
|
|
|
2 |
|
BUSHING
|
|
|
3 |
|
SHAFT
|
|
|
4 |
JKX8087-367 |
VALVE
|
|
|
5 |
|
BUSHING
|
|
|
6 |
JK1100-0725 |
BOLT
|
|
|
7 |
|
SEAL,RING
|
|
|
8 |
|
SEAL,RING
|
|
|
9 |
JK281-20535 |
COVER
|
|
|
10 |
JKX8087-369 |
PLATE
|
|
|
11 |
JK1100-0760 |
BOLT
|
|
|
12 |
JK0151-0805 |
NUT
|
|
|
13 |
JK1120-0348 |
SCREW
|
|
|
14 |
JK1105-0047 |
BOLT,FLANGE
|
|
|
15 |
JK1113-0285 |
NUT,FLANGE
|
|
|
16 |
JK281-22173 |
LEVER
|
|
|
|$20 |
JK284-01063 |
CONTROL ASS'Y
|
|
|
|$21 |
JK284-10707 |
CYLINDER ASS'Y
|
|
|
17 |
|
CYLINDER
|
|
|
18 |
JK1261-0232 |
BUSH
|
|
|
19 |
JK1306-0081 |
SEAL,DUST
|
|
|
20 |
JK1411-0591 |
SPRING
|
|
|
21 |
JK284-20621 |
SHAFT
|
|
|
22 |
JK284-22105 |
PROTECTOR,CYLINDER
|
|
|
23 |
|
PISTON
|
|
|
24 |
JK284-22007 |
RING,WEAR
|
|
|
25 |
JK1310-0264 |
PACKING,CUP
|
|
|
26 |
JK1132-0255 |
WASHER
|
|
|
27 |
JK1113-0285 |
NUT,FLANGE
|
|
|
28 |
JK1173-0016 |
O-RING
|
|
|
29 |
JK284-20507 |
COVER
|
|
|
30 |
JK0801-0820 |
BOLT,WITH WASHER
|
|
|
31 |
JK652-21900 |
FILTER
|
|
|
32 |
JK0410-1210 |
RING,RETAINING
|
|
|
33 |
JK284-22203 |
GUIDE
|
|
|
34 |
|
PROTECTOR
|
|
|
35 |
|
LABEL
|
|
|
36 |
JK1105-0166 |
BOLT
|
|
|
37 |
JK1113-0281 |
NUT
|
|
|
38 |
JK1291-0200 |
CLEVIS
|
|
|
39 |
JK1155-0074 |
PIN
|
|
|
40 |
JK286-20111 |
PIN
|
|
|
41 |
JK286-20649 |
INSULATOR
|
|
|
42 |
|
LABEL
|
