| 1 | 600-825-6150 | ALTERNATOR A. (60A),(SEE FIG.A6010-C3M8) | |
| |1 | 600-821-8830 | ALTERNATOR A. (50A),(SEE FIG.A6010-B3M8) | |
| 2 | 6128-21-6780 | BOLT | |
| 3 | 02205-10812 | NUT | |
| 4 | 01640-21323 | WASHER | |
| 5 | 21T-72-14350 | SPACER | |
| 6 | 560-43-12470 | SPACER | |
| 7 | 6150-81-6470 | BRACKET | |
| 8 | 01010-81060 | BOLT | |
| 9 | 6150-82-8650 | PLATE | |
| 10 | 01010-81065 | BOLT | |
| 11 | 01643-31032 | WASHER | |
| 12 | 6206-11-4490 | SPACER | |
| 13 | 6150-82-8610 | ROD | |
| 14 | 01010-81255 | BOLT | |
| 15 | 01643-31232 | WASHER | |
| 16 | 6215-81-6150 | PIN | |
| 17 | 01580-11210 | NUT | |
| 18 | 6150-82-8690 | PLATE | |
| 19 | 01580-11411 | NUT | |
| 20 | 01050-51255 | BOLT | |
| 21 | 01640-21223 | WASHER |
