| 1 | 6211-12-5690 | MUFFLER | |
| 2 | 6211-12-5830 | BRACKET | |
| 3 | 01010-81095 | BOLT | |
| 4 | 6136-11-5120 | SPACER | |
| 5 | 01010-81030 | BOLT | |
| 6 | 6215-11-5750 | BAND | |
| 7 | 6215-11-5740 | NUT | |
| 8 | 6211-12-5480 | BRACKET | |
| 9 | 01010-81025 | BOLT | |
| 10 | 01643-31032 | WASHER | |
| 11 | 01010-81030 | BOLT | |
| 12 | 01010-81055 | BOLT | |
| 13 | 01643-31032 | WASHER | |
| 14 | 01580-11008 | NUT | |
| 15 | 6211-12-5860 | TUBE,DRAIN | |
| 16 | 6991-11-5990 | CLAMP | |
| 17 | 01010-81020 | BOLT | |
| 18 | 01640-21016 | WASHER | |
| 19 | 01580-11008 | NUT | |
| 20 | 01010-81020 | BOLT |
