Запчасти боков. сдвиг сцепн. устр-ва цилиндр (внутр. части) грейдеры gd655-3y s/n 4001-up Komatsu



|1 707-00-0C160 CYLINDER ASS'Y
|1 707-00-07G20 CYLINDER GROUP,(FINAL COATING)
1 707-11-80C40 CYLINDER
2 07138-00980 CAP,CYLINDER
3 07020-00900 FITTING,GREASE
4 07141-00090 SEAL,DUST (KIT)
5 07139-00902 SHIM¤ 0.2MM
|5 07139-00905 SHIM¤ 0.5MM
6 01010-82075 BOLT
7 01580-12016 NUT
8 01643-32060 WASHER
9 707-29-80930 HEAD,CYLINDER
10 07177-04530 BUSHING
11 707-51-45210 PACKING,ROD (KIT)
12 112-63-15370 SEAL,DUST (KIT)
13 07179-12057 RING,SNAP
14 07000-12075 O-RING (KIT)
15 07001-02075 RING,BACK-UP (KIT)
16 07000-12080 O-RING (KIT)
17 707-60-45010 ROD,PISTON
18 07138-00980 CAP,ROD
19 07020-00900 FITTING,GREASE
20 07141-00090 SEAL,DUST (KIT)
21 07139-00902 SHIM¤ 0.2MM
|21 07139-00905 SHIM¤ 0.5MM
22 01010-82075 BOLT
23 01580-12016 NUT
24 01643-32060 WASHER
25 707-36-80911 PISTON
26 07155-00820 RING,WEAR (KIT)
27 707-44-80070 RING,PISTON (KIT)
28 07165-12729 NUT,NYLON
29 02896-11009 O-RING (KIT)
K 707-98-24320 SERVICE KIT,DRAWBAR SIDE SHIFT CYLINDER
