| 1 | 23B-43-31491 | PEDAL | |
| 2 | 04210-20832 | YOKE | |
| 3 | 01580-10806 | NUT | |
| 4 | 04205-30822 | PIN | |
| 5 | 04052-10833 | PIN,SNAP | |
| 6 | 08037-01610 | GROMMET | |
| 7 | 23B-43-31102 | PEDAL,ACCELERATOR | |
| 8 | 01010-80620 | BOLT | |
| 9 | 01643-30623 | WASHER | |
| 10 | 23B-45-32102 | PEDAL,INCHING | |
| 11 | 01010-80620 | BOLT | |
| 12 | 01643-30623 | WASHER | |
| 13 | 23B-43-31113 | LEVER | |
| |13 | 232-14-67150 | BUSHING | |
| |13 | 06600-00805 | BUSHING | |
| 14 | 01640-22440 | WASHER | |
| 15 | 04064-02512 | RING,SNAP | |
| 16 | 23B-43-31180 | ROD | |
| 17 | 04256-40615 | JOINT,ROD | |
| 18 | 01640-20610 | WASHER | |
| 19 | 01643-30623 | WASHER | |
| 20 | 04256-30615 | JOINT | |
| 21 | 01508-40603 | NUT | |
| 22 | 01643-30623 | WASHER | |
| 23 | 232-43-42330 | SPRING | |
| 24 | 23D-43-31430 | BUSHING | |
| 25 | 23B-43-31220 | BRACKET | |
| 26 | 01010-81020 | BOLT | |
| 27 | 01643-31032 | WASHER | |
| 28 | 01580-10605 | NUT |
