| 1 | 238-54-11190 | BRACKET | |
| 1 | 233-54-21250 | BRACKET,(WITH MIRROR) | |
| 2 | 01010-51230 | BOLT | |
| 3 | 01010-51235 | BOLT | |
| 4 | 01643-31232 | WASHER | |
| 5 | 01643-31232 | WASHER | |
| 6 | 238-54-11140 | GUARD | |
| 7 | 01010-51260 | BOLT | |
| 8 | 01643-31232 | WASHER | |
| 9 | 01580-11210 | NUT | |
| 10 | 08174-10001 | MIRROR | |
| 11 | 232-06-15151 | PIVOT,(WITH MIRROR) | |
| 12 | 01010-50825 | BOLT,(WITH MIRROR) | |
| 13 | 01580-10806 | NUT,(WITH MIRROR) | |
| 14 | 01643-30823 | WASHER,(WITH MIRROR) |
