Запчасти фальцевальный цилиндр (для усил. снегоочист. систмы)(№-) грейдеры gd705a-4a s/n 11001-up Komatsu
|
|
|1 |
234-977-4140 |
CYLINDER ASS'Y,HOLD¤ L.H.
|
|
|
|1 |
234-977-4130 |
CYLINDER ASS'Y,HOLD¤ R.H.
|
|
|
1 |
234-977-4580 |
COVER,ROD¤ L.H.
|
|
|
|1 |
234-977-4321 |
COVER,ROD¤ R.H.
|
|
|
2 |
234-977-4570 |
COVER,HEAD¤ L.H.
|
|
|
|2 |
234-977-4311 |
COVER,HEAD¤ R.H.
|
|
|
3 |
234-977-4211 |
TUBE,CYLINDER
|
|
|
4 |
234-977-4231 |
ROD,PISTON
|
|
|
5 |
234-977-4221 |
PISTON
|
|
|
6 |
234-977-4421 |
RETAINER
|
|
|
7 |
234-977-4351 |
BUSHING
|
|
|
8 |
234-977-4251 |
RING,CUSHION
|
|
|
9 |
234-977-4491 |
ROD,TIE
|
|
|
10 |
234-977-4431 |
VALVE,CUSHION
|
|
|
11 |
234-977-4441 |
NUT,LOCK
|
|
|
12 |
234-977-4451 |
PLUG,CHECK
|
|
|
13 |
234-977-4461 |
SPRING,CHECK
|
|
|
14 |
234-977-4471 |
BALL,CHECK
|
|
|
15 |
234-977-4550 |
SCREW
|
|
|
16 |
234-977-4560 |
BALL
|
|
|
17 |
234-977-4511 |
NUT
|
|
|
18 |
234-977-4531 |
WASHER,SPRING
|
|
|
19 |
234-977-4241 |
SCREW,SET
|
|
|
20 |
234-977-4261 |
PACKING,PISTON
|
|
|
21 |
234-977-4371 |
PACKING,ROD
|
|
|
22 |
234-977-4381 |
SEAL,DUST
|
|
|
23 |
234-977-4341 |
O-RING
|
|
|
24 |
234-977-4391 |
O-RING
|
|
|
25 |
234-977-4271 |
O-RING
|
|
|
26 |
234-977-4481 |
SEAL,CUSHION VALVE
|
|
|
27 |
234-977-4540 |
BRACKET
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
18
19
20
20
21
22
23
23
24
25
26
27
27
