| 1 | 234-46-44101 | FRAME,REAR | |
| |1 | 234-46-44100 | FRAME,REAR | |
| |1 | 234-46-00220 | FRAME,REAR | |
| 2 | 234-46-42250 | CAP | |
| |2 | 234-46-32581 | CAP | |
| 3 | 234-46-01010 | SHIM ASS'Y | |
| |3 | SHIM¤ 0.2MM | ||
| |3 | SHIM¤ 0.5MM | ||
| |3 | SHIM¤ 1.0MM | ||
| 4 | 01011-82455 | BOLT | |
| 5 | 01643-32460 | WASHER | |
| 6 | 234-46-42240 | SPACER | |
| 7 | 232-46-53210 | BUSHING | |
| 8 | 236-46-13380 | BUSHING | |
| 9 | 236-46-13390 | BUSHING | |
| 10 | 236-46-13610 | O-RING | |
| 11 | 235-46-11710 | BOLT | |
| |11 | 236-46-13620 | BOLT | |
| 12 | 01598-00608 | NUT | |
| |12 | 01598-10608 | NUT | |
| 13 | 01640-20610 | WASHER | |
| 14 | 232-46-54190 | PIN | |
| 15 | 236-46-13410 | NUT | |
| 16 | 236-46-13420 | PLATE | |
| 17 | 01010-51630 | BOLT | |
| 18 | 01643-31645 | WASHER | |
| 19 | 01643-31645 | WASHER | |
| 20 | 232-46-54560 | ELBOW | |
| 21 | 232-46-54570 | TUBE | |
| 22 | 232-46-54571 | TUBE | |
| 23 | 07020-00000 | FITTING,GREASE | |
| 24 | 01010-51250 | BOLT | |
| 25 | 01643-31232 | WASHER | |
| 26 | 232-46-11711 | PIN | |
| 27 | 04025-01065 | PIN,SPRING | |
| 28 | 232-46-11920 | PIN,SNAP | |
| 29 | 07049-02430 | PLUG |
