| 1 | 23C-843-5120 | WIRING HARNESS | |
| 2 | 04434-51410 | CLIP | |
| 3 | 04434-52310 | CLIP | |
| 4 | 04434-52711 | CLIP | |
| 5 | 01010-81016 | BOLT | |
| 6 | 01643-31032 | WASHER | |
| 7 | 7861-92-4130 | POTENTIOMETER | |
| 8 | 01252-70612 | BOLT | |
| 9 | 01643-30623 | WASHER | |
| 10 | 23F-843-3140 | COUPLING | |
| 11 | 23F-843-3270 | BUSHING | |
| 12 | 23F-843-3260 | SPROCKET | |
| 13 | 01252-60410 | BOLT | |
| 14 | 23F-843-3250 | JOINT | |
| 15 | 01252-60410 | BOLT | |
| 16 | 01640-20408 | WASHER | |
| 17 | 01643-30823 | WASHER | |
| 18 | 23F-843-3240 | PIN | |
| 19 | 23C-843-5240 | BRACKET | |
| 20 | 01010-81280 | BOLT | |
| 21 | 01643-31232 | WASHER | |
| 22 | 23F-843-3180 | COVER | |
| 23 | 01010-81020 | BOLT | |
| 24 | 01643-31032 | WASHER | |
| 25 | 08034-20519 | BAND | |
| 26 | 23C-843-5250 | BRACKET | |
| 27 | 01010-80820 | BOLT | |
| 28 | 01643-30823 | WASHER | |
| 29 | 23F-843-3190 | CHAIN | |
| 30 | 23F-843-3210 | HOLDER | |
| 31 | 01252-70825 | BOLT | |
| 32 | 23F-843-3220 | HOLDER | |
| 33 | 23F-843-3230 | COVER | |
| 34 | 01252-70410 | BOLT |
