| 1 | 23A-54-24312 | GRILLE | |
| 2 | 08037-03614 | GROMMET | |
| 3 | 08037-01008 | GROMMET | |
| 4 | 205-60-71220 | LOCK ASS'Y | |
| 5 | 23B-54-16510 | PLATE,BAFFLE | |
| 6 | 23B-54-15890 | PLATE | |
| 7 | 23A-54-24320 | PLATE,BAFFLE | |
| 8 | 23A-54-17540 | PLATE | |
| 9 | 01220-40620 | SCREW | |
| 10 | 01580-10605 | NUT | |
| 11 | 01643-30623 | WASHER | |
| 12 | 23A-54-17121 | COVER | |
| 13 | 01010-81025 | BOLT | |
| 14 | 01643-31032 | WASHER | |
| 15 | 234-54-13252 | WASHER | |
| 16 | 01010-81025 | BOLT | |
| 17 | 01643-31032 | WASHER | |
| 18 | 23A-54-22112 | HOOD | |
| 19 | 23A-956-1111 | PIPE,EXHAUST | |
| 20 | 01010-81025 | BOLT | |
| 21 | 01643-31032 | WASHER | |
| 22 | 232-43-58360 | WASHER | |
| 23 | 23B-54-15590 | PLATE | |
| 24 | 01010-81020 | BOLT | |
| 25 | 01643-31032 | WASHER | |
| 26 | 234-54-13252 | WASHER | |
| 27 | 23B-54-15910 | PLATE | |
| 28 | 01010-81020 | BOLT | |
| 29 | 01643-31032 | WASHER | |
| 30 | 234-54-13252 | WASHER | |
| 31 | 01010-81025 | BOLT | |
| 32 | 01643-31032 | WASHER | |
| 33 | 234-54-13252 | WASHER |
