| 1 | 233-43-27110 | BRACKET | |
| 2 | 234-885-1620 | BUSHING | |
| 3 | 04025-00532 | PIN | |
| 4 | 233-43-27220 | BRACKET | |
| 5 | 234-885-1620 | BUSHING | |
| 6 | 233-43-27241 | PLATE | |
| 6 | 233-43-27240 | PLATE | |
| 7 | 01010-50820 | BOLT | |
| 8 | 01602-20825 | WASHER | |
| 9 | 233-43-27250 | HANDLE | |
| 10 | 233-43-27350 | BRACKET | |
| 11 | 234-885-1620 | BUSHING | |
| 12 | 233-43-27360 | BRACKET | |
| 13 | 234-885-1620 | BUSHING | |
| 14 | 04025-00532 | PIN | |
| 15 | 233-43-27370 | BRACKET | |
| 16 | 234-885-1620 | BUSHING | |
| 17 | 233-43-27380 | SLIDER | |
| 18 | 234-885-1620 | BUSHING | |
| 19 | 234-885-1610 | BUSHING | |
| 20 | 233-43-27120 | BRACKET | |
| 21 | 01010-51225 | BOLT | |
| 22 | 01602-21236 | WASHER | |
| 23 | 04025-00532 | PIN | |
| 24 | 233-43-27390 | SHAFT | |
| 25 | 04064-02012 | RING | |
| 26 | 233-43-27310 | SHAFT | |
| 27 | 233-43-27320 | SHAFT | |
| 28 | 233-43-27330 | SHAFT | |
| 29 | 233-43-27340 | SHAFT | |
| 30 | 232-43-58360 | WASHER | |
| 31 | 01010-51225 | BOLT | |
| 32 | 01602-21236 | WASHER | |
| 33 | 232-43-58370 | SHIM, 0.5MM | |
| 34 | 232-43-58380 | SHIM, 0.2MM |
