| 1 | 232-60-54110 | NIPPLE | |
| 2 | 07002-12034 | O-RING (KIT) | |
| 3 | 232-60-54120 | TUBE | |
| 4 | 232-60-54130 | TUBE | |
| 5 | 232-60-54250 | TUBE | |
| 6 | 232-60-54260 | TUBE | |
| 7 | 232-60-54230 | TUBE | |
| 8 | 232-60-54240 | TUBE | |
| 9 | 232-60-54340 | TUBE | |
| 10 | 232-60-54350 | TUBE | |
| 11 | 232-60-54360 | TUBE | |
| 12 | 07230-10422 | UNION | |
| 13 | 07002-12034 | O-RING (KIT) | |
| 14 | 232-60-00341 | VALVE ASS'Y,(SEE FIG.622) | |
| 14 | 232-60-00340 | VALVE ASS'Y,(SEE FIG.622) | |
| 15 | 01010-50875 | BOLT | |
| 16 | 01602-20825 | WASHER | |
| 17 | 07235-10422 | ELBOW | |
| 18 | 07002-12034 | O-RING (KIT) | |
| 19 | 07108-20410 | HOSE | |
| 19 | 07109-20411 | HOSE | |
| 19 | 07108-20411 | HOSE | |
| 19 | 07123-00411 | HOSE | |
| 20 | 232-60-54370 | TUBE | |
| 21 | 01010-51020 | BOLT | |
| 22 | 01602-21030 | WASHER | |
| 23 | 232-60-14271 | NIPPLE | |
| 24 | 07002-12434 | O-RING (KIT) | |
| 25 | 236-60-00080 | VALVE ASS'Y,(SEE FIG.623) | |
| 25 | 234-60-00150 | VALVE ASS'Y,PILOT CHECK (SEE FIG.623) | |
| 26 | 01010-50875 | BOLT | |
| 27 | 01602-20825 | WASHER | |
| 28 | 232-60-54380 | NIPPLE | |
| 29 | 232-60-14281 | ELBOW | |
| 30 | 07002-12434 | O-RING (KIT) | |
| 31 | 07108-20410 | HOSE | |
| 31 | 07109-20411 | HOSE | |
| 31 | 07108-20411 | HOSE | |
| 31 | 07123-00411 | HOSE | |
| 32 | 232-60-54871 | PLATE | |
| 32 | 232-60-54870 | PLATE | |
| 33 | 01010-51020 | BOLT | |
| 34 | 01602-21030 | WASHER | |
| 35 | 232-60-54830 | CLIP | |
| 36 | 01010-51045 | BOLT | |
| 37 | 01602-21030 | WASHER | |
| 38 | 07235-50422 | ELBOW | |
| 39 | 07042-20108 | PLUG |
