| 1 | 07108-20407 | HOSE | |
| |1 | 07123-00407 | HOSE | |
| 2 | 07102-20307 | HOSE | |
| |2 | 07100-20307 | HOSE | |
| 3 | 232-60-54510 | TUBE | |
| 4 | 232-60-54520 | TUBE | |
| 5 | 232-60-54530 | TUBE | |
| 6 | 232-60-54540 | NIPPLE | |
| 7 | 232-60-54550 | ELBOW | |
| 8 | 07002-13034 | O-RING (KIT) | |
| 9 | 234-943-6260 | ELBOW | |
| 10 | 232-60-54890 | CLIP | |
| 11 | 01010-51035 | BOLT | |
| 12 | 01602-21030 | WASHER | |
| 13 | 232-60-54560 | TUBE | |
| 14 | 232-60-54570 | TUBE | |
| 15 | 237-60-14130 | CLIP | |
| 16 | 01010-51035 | BOLT | |
| 17 | 01602-21030 | WASHER | |
| 18 | 232-60-14791 | NIPPLE | |
| 19 | 07002-12434 | O-RING (KIT) | |
| 20 | 232-60-14292 | NIPPLE | |
| 21 | 234-60-22732 | TUBE | |
| 22 | 234-60-22742 | TUBE | |
| 23 | 234-60-22750 | ELBOW | |
| 24 | 234-60-00150 | VALVE ASS'Y,PILOT CHECK (SEE FIG.623) | |
| 25 | 233-60-14981 | BOLT | |
| 26 | 01602-20825 | WASHER | |
| 27 | 232-60-14281 | ELBOW | |
| 28 | 07002-12434 | O-RING (KIT) | |
| 29 | 232-60-54580 | TUBE | |
| 30 | 232-60-54590 | TUBE | |
| 31 | 07109-20408 | HOSE | |
| 32 | 232-60-54610 | TUBE | |
| 33 | 232-60-54620 | TUBE | |
| |35 | 232-60-00360 | JOINT ASS'Y | |
| 35 | 232-60-54710 | BODY | |
| 36 | 232-60-54720 | FLANGE | |
| 37 | 07043-00211 | PLUG | |
| 38 | 07000-13050 | O-RING (KIT) | |
| 39 | 232-60-54730 | PLATE | |
| 40 | 01010-51225 | BOLT | |
| 41 | 01602-21236 | WASHER | |
| 42 | 01010-51240 | BOLT | |
| 43 | 01602-21236 | WASHER | |
| 44 | 01580-11210 | NUT | |
| 45 | 07235-10422 | ELBOW | |
| 46 | 07002-12034 | O-RING (KIT) | |
| 47 | 232-60-54630 | TUBE | |
| 48 | 07109-20405 | HOSE | |
| 49 | 232-60-54640 | TUBE | |
| 50 | 01010-51020 | BOLT | |
| 51 | 01602-21030 | WASHER | |
| 52 | 232-60-54650 | ELBOW | |
| 53 | 07002-12034 | O-RING (KIT) |
