| 1 | 236-54-27112 | FENDER,L.H. | |
| |1 | 236-54-27111 | FENDER,L.H. | |
| 2 | 236-54-27122 | FENDER,R.H. | |
| |2 | 236-54-27121 | FENDER,R.H. | |
| 3 | 01010-51225 | BOLT | |
| |3 | 01010-31220 | BOLT | |
| 4 | 01602-21236 | WASHER | |
| |4 | 01602-01236 | WASHER | |
| 5 | 236-54-27131 | GUARD | |
| |5 | 236-54-27130 | GUARD | |
| 6 | 236-54-27141 | PLATE | |
| |6 | 236-54-27140 | PLATE | |
| 7 | 01010-50612 | BOLT | |
| |7 | 01010-30612 | BOLT | |
| 8 | 01602-20619 | WASHER | |
| |8 | 01602-00619 | WASHER | |
| |9 | 234-46-00020 | TOOL BOX ASS'Y | |
| 9 | 234-46-14110 | BOX | |
| 10 | 232-46-13310 | PADLOCK | |
| 11 | 01010-51220 | BOLT | |
| |11 | 01010-31220 | BOLT | |
| 12 | 01602-21236 | WASHER | |
| |12 | 01602-01236 | WASHER | |
| 13 | 01640-21223 | WASHER | |
| |13 | 01640-01223 | WASHER | |
| 14 | 236-54-27150 | BRACKET | |
| 15 | 236-54-27160 | BRACKET | |
| 16 | 236-54-27170 | BRACKET | |
| 17 | 236-54-27180 | BRACKET | |
| 18 | 01010-51016 | BOLT | |
| 19 | 01602-21030 | WASHER | |
| 20 | 01640-21016 | WASHER | |
| 21 | 01640-21223 | WASHER |
