Запчасти основн. поршень насос внутр. части (7/) (№c-) экскаваторы pc300-8 s/n c50001-up Komatsu



|$0 708-2G-00700 Pump Assembly
|$1 708-2G-01073 Pump Subassembly
1 708-2G-12190 Shaft
2 708-2G-12251 Bearing
3 708-2G-05010 Washer Kit
|$5 Washer, 3.0mm
|$6 Washer, 3.1mm
|$7 Washer, 3.2mm
4 708-1F-12270 Ring, Snap
|$9 708-2G-04272 Block Assembly, Rear
5 Cylinder Block
6 Plate, Valve
7 708-18-13230 Pin
8 04065-05520 Ring, Snap, for Hole Side
9 708-2G-13131 Seat
10 708-2G-13152 Spring
11 708-2G-13141 Seat
12 708-2G-13510 Guide, Retainer
13 708-2H-23360 Pin
14 708-2G-13341 Retainer, Shoe
15 708-2G-13370 Piston Subassembly
|$21 708-2G-04290 Cradle Subassembly
16 Cradle
17 Cam, Rocker
18 04020-01434 Pin, Dowel
19 07000-B1009 O-ring
20 01252-61230 Bolt
20
18
17
16
15
14
13
12
11
10
9
8
7
6
5
2
3
4
1
19
