Запчасти возд. влагоотделитель(№-.) грейдеры gd825a-2 s/n 11001-up Komatsu
|
|
1 |
235-44-11770 |
AIR DRYER ASS'Y,(DR-3U)
|
|
|
|2 |
235-44-13700 |
VALVE BODY ASS'Y
|
|
|
2 |
|
BODY,VALVE
|
|
|
3 |
|
O-RING (K4)
|
|
|
4 |
|
O-RING (K4)
|
|
|
5 |
|
PISTON
|
|
|
6 |
|
O-RING
|
|
|
7 |
|
VALVE ASS'Y (K4)
|
|
|
8 |
|
SPRING,VALVE (K4)
|
|
|
9 |
|
BOLT
|
|
|
10 |
|
WASHER,SPRING
|
|
|
11 |
|
COVER,EXHAUST
|
|
|
12 |
|
FILTER (K4)
|
|
|
13 |
|
DESICCANT (K4)
|
|
|
14 |
|
GASKET,FILTER (K4)
|
|
|
15 |
|
FILTER,OIL (K4)
|
|
|
16 |
|
RING,GASKET (K4)
|
|
|
17 |
|
RING,SEAL (K4)
|
|
|
18 |
|
O-RING (K4)
|
|
|
19 |
235-44-13770 |
HEATER
|
|
|
20 |
235-44-13900 |
THERMOSTAT ASS'Y
|
|
|
21 |
|
BOOT,HEATER
|
|
|
22 |
|
TERMINAL
|
|
|
23 |
|
CLAMP
|
|
|
24 |
|
CAP
|
|
|
25 |
|
TERMINAL
|
|
|
26 |
|
O-RING (K4)
|
1
1
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
